Bơm nước muối Nova Salt

TECHNICAL DATA

Operating range: from 1 to 7.5 m3 /h with head up to 6 metres.

Liquid temperature range: from 0 °C to +35 °C for domestic use.

Pumped liquid: dirty water, without fibre, including salt water.

Max. immersion depth: 7 metres.

APPLICATIONS

The vertical delivery draining submersible pump has been specifically built for draining applications in salt water installations. It may also be used as a portable pump in emergency situations. The built-in float level switch, in the automatic version, allows fixed installation, ensuring automatic operation.

CONSTRUCTION FEATURES OF THE PUMP

Hydro resistant technopolymer pump body, cover, and suction grid. AISI 316 stainless steel motor, rotor shaft, and bolts and screws. Cable with tin plated conductors.

CONSTRUCTION FEATURES OF THE MOTOR

Submersible type continuous duty asynchronous motor. Thermal overheating protection.
